ET 1100
Superior high quality, technically advanced, Thermal and Electrical, Non Asbestos, Non Concrete Based, Composite Insulation Sheet.
White in colour ET 1100 is a fibre glass laminated thermoset composite with an inorganic and silicon substrate filler binder.
ET 1100 performance is similar to that of ET 1200 except that it has a lower constant heat resistant temperature rating (300 degrees Centigrade in comparison to ET 1200’s 350 degrees Centigrade)
ET 1100 is one of the most popular insulation materials due to versatility and economical pricing.
ET 1100 also has a heat resistance rating higher than “H” and has been graded incombustible under Fire Resistance testing ASTM D 635 (JISK 6911 A) and has a 94V – 0 rating under JIS K 6911 B.
Thickness available 1mm – 30mm
Sheet sizes available 1 metre x 1 metre and 1 metre x 1.25 metre
Weight Approximately 2.4 kg per 1mm of thickness x 1 metre square
ET 1100 is also versatile, mechanically stronger and with a higher binding
strength and more economically priced than ET 1200.
A resilient insulation material, ET 1100 applications are also similar as ET 1200.
Some of these we have listed below:
Thermal Shields
Heavy Duty Insulation for Electrical Equipment
Control Equipment
Arc Chutes
Thermal Gaskets
Thermal Boards
Resistor Panels
Dynamic Brake Grids
Thermal Presses
These are only a few suggestions, the list is endless, the more innovative
the design the more chance of utilizing ET 1100 excellent insulation properties.
